• Satin Stainless Steel (US32D)

    • Oil Rubbed Bronze (US10B)

    • Matte Black (US19)

  • Outside Trims

    • 900ELC Heavy Duty Escutcheon Lever Trim

      • Finish: US32D, US10B, US19

      • Functions (ANSI):

        • 908ELC Entrance (08)

        • 914 ELC: Passage (14)

        • 909ELC: Storeroom (03)

        • 902 ELC: Dummy (02)

    Strikes & Fillers

    • V/R Top Strike

    • V/R Bottom Strike

    • Optional Bottom Strike

    • Filler (9222): Latch Front Filler (1-1/8” x 2-1/4”)

    • Filler (9209): ASA Strike Filler (1-1/4” x 4-7/8”)

    • Extension Rod (ETR12C) - 1” extension - To extend the top rod only

    Accessories

    • 1344 - Sex Bolts 1-3/4” - 2” Door - 98/99 (4 PCS)

    • 2144 - Sex Bolts 2-1/4” Door - 98/99 Series (4 PCS)

    • Dogging Key (9201-29)

    • Cylinder Dogging Kit

      • 9CD36 - For Exit Device 36”

      • 9CD48 - For Exit Device 48”

    • Alarm Kit with Decal

      • 9AK36 - For Door Width 36”

      • 9AK48 - For Door Width 48”

    • ANSI Grade 1 Approved, Exceeds 500,000 cycles

    • UL Listed for up to 3 hours on “A” label fire doors

    • UL306 Listed for Panic Hardware

    • UL10B Neutral Pressure Rated

    • UL10C/UBC7-2 (1997) Positive Pressure Rated

    • Comply with ANSI117.1 for accessible and usable buildings and facilities standards

Specifications:

Structure

  • Head Cover – Plated Zinc Alloy

  • Chassis – Steel or Stainless Steel

  • End Cap – Plated Zinc Alloy

  • Rail Assembly – Heavy Gauge Extruded Aluminum

Door Fitting

  • 1-3/4”~ 2” thick standard.

Door Width

  • 36”, rail can be cut from the end to fit door size down to 30”

  • 48”, rail can be cut from the end to fit door size down to 40”

Dimensions

  • Projection: 3-17/64” Maximum

  • Overall Size: 8-5/64”H x 33-5/32”W or 45-5/32”W

Latch Bolt

  • Stainless Steel

  • Top Latch: 3/4” throw.

  • Bottom Latch: 1/2” throw

Strike

  • Top: 9172C - Standard Top Strike

  • Bottom: SVRCBS75 Standard Mortise In Bottom Strike

    • 9573C Alternative Bottom Strike

Fasteners

  • 9900 – Furnished with Wood & Machine Screws

  • F9900 – Furnished with Wood & Machine Screws and extra Sex Bolts

Handing

  • Reversible non-handed

Dogging

  • Standard for 9900 (Non Rated)

  • Cylinder Dogging Kit 9CD36/9CD48 available.

Alarm

  • Alarm Kit 9AK36/9AK48 available
